Alumina Fiber Board for Industrial Furnace Insulation

Alumina Fibre Board Applications

These cases show that alumina fiber boards improve energy efficiency, process stability, and equipment reliability across a wide range of high-temperature industries, demonstrating their value in real applications.

• Industrial Furnaces — Hot-Face & Back-Up Panels

  ✅Key Advantages

  1. Low shrinkage at temperature: Holds seal lines during cycling, minimizing heat leaks.
  2. Stable conductivity at mid/high-temp: Supports tighter temperature bands for process consistency.
  3. Rigid & machinable: Clean slots/holes ensure fast fit with existing anchors and carriers.

  ✅ Problem Solved

  Retrofitting a mixed-load heat-treat line required maintaining ±10 °C uniformity at 900–1050 °C while cutting energy use. Replacing aged boards with high-alumina sheets plus a 25 mm back-up layer reduced burner duty, improved side-to-center delta by ~8–12 °C, and shortened ramp-up by ~10–15 min per cycle. The line avoided unscheduled downtime and brought maintenance intervals back on plan.

• Advanced Materials & Powder Metallurgy — Sintering Cells

  ✅Key Advantages

  1. Clean surface & low particulates: Helps protect sensitive green parts and fixtures.
  2. Flatness control: Supports repeatable stack-ups and fixture alignment.
  3. Thermal stability: Reduces dimensional drift across long holds and multiple cycles.

  ✅ Problem Solved

  A sintering cell handling fragile compacts saw edge erosion on the hot-face. Switching to flatness-controlled alumina fiberboard sheets with sealed hot-face reduced debris accumulation, cut fixture re-shimming time by ~30–40%, and stabilized length change across batches.

• Industry: Kiln Energy Retrofit — Back-Up & Baffle Panels

  ✅Key Advantages
  1. Lower heat loss: Reduced wall flux improves energy balance at steady state.
  2. Easy machining: Large pass-throughs and baffles shaped without complex tooling.
  3. Fast install: Rigid sheets anchor cleanly, enabling phased upgrades during short outages.

  ✅ Problem Solved

  A periodic kiln targets energy savings without extending downtime. Installing 50 mm alumina insulation ceramic fibre boards behind the hot face lowered fuel consumption per firing cycle by a measured single-digit percentage and kept product profiles within spec, avoiding post-firing rework.

Alumina Fiberboard Sheets Usage Instructions

• Installation

  1. Cut with a standard ceramic saw or a CNC router
  2. Use high-temperature adhesive or mechanical fasteners
  3. Ensure tight joints to minimize heat leakage

• Storage

  1. Store in a dry, ventilated area
  2. Avoid direct contact with water or oil

• Cleaning

  1. Use a dry cloth or compressed air
  2. Do not use water or chemical cleaners

• Maintenance Tips

  1. Inspect regularly for cracks or shrinkage
  2. Replace damaged sections to maintain insulation performance
  3. Avoid mechanical impact during installation

• Common Mistakes

  1. Over-tightening fasteners may cause cracking
  2. Using in environments above the rated temperature reduces lifespan

Alumina Fiber Board FAQ

1. Q: Can I use alumina fiber board as a structural support?
   A: No, it is not designed for load-bearing applications.
2. Q: What is the difference between alumina fiber board and general ceramic fiber board?
   A: Alumina fiber board contains higher Al₂O₃, offering higher continuous temperature resistance, lower shrinkage, and cleaner surfaces than general ceramic fiber board.
3. Q: Do you supply standard alumina fiberboard sheets?
   A: Yes. Common sheets include 900×600 mm and 1000×500 mm with multiple thicknesses; other cuts are available.
4. Q: Can I request custom machining (slots/holes/chamfers)for alumina fiber board?
   A: Yes. Provide drawings with positions, tolerances, and edge quality requirements; we return manufacturability notes.
5. Q: What thickness should I choose?
   A: Select thickness from your heat-loss model and mechanical constraints; many retrofits use 25–50 mm per layer.
6. Q: Is this Al2O3 fiber board suitable for direct flame contact?
   A: Al₂O₃ fiber board is not suitable for continuous direct flame impingement, as hot gas flow can cause surface erosion and fiber pull-out. It should be positioned behind refractory tiles or coatings to maintain insulation performance and service life.
